Description
The Abkoncore Mighty 600Watt is an ATX 12V power supply with a power of 600 Watt and an efficiency of 85%. The power supply has 4 SATA and 2 PCI-e 6+2 Pins connections.
Main Specifications:
Power (continuous): 600 Watt
Certificate: 80 Plus Standard
Modular (PSU): Non-modular
Brand: ABKONCORE
LED lighting: No
EAN: 8809622472804
SKU: ABKO-PSU-230V-600W
All Specifications
Brand: ABKONCORE
EAN: 8809622472804
SKU: ABKO-PSU-230V-600W
Connections
CPU power connection (4 + 4 pin): Yes
Motherboard power connection: 24-pin ATX
Molex power connection (s): 2
PCI Express power connector (s) (6 + 2 pin): 2
SATA power connector (s): 4
Physical properties
Width: 150 mm
Depth: 140 mm
Weight: 1.38 kg
Height: 86 mm
Color of product: Black
Cooling
Fan diameter: 12 cm
Cooling type: Active
Technical details
ATX Version: 2.52
Intended for: PC
Certificates
80 PLUS certification: 80 PLUS
Energy
Efficiency: 85 percent
Input voltage: 200 – 240 V
Max output current (+ 12V): 45 A
Max output current (+ 3.3V): 17 A
Max output current (+ 5V): 17 A
Max output current (+ 5Vsb): 3 A
Max output current (-12V): 0.3 A
Power Factor Correction (PFC) type: Active
Power supply: 600 W
