MSI H110M Pro VH Plus Features: Motherboard | M-ATX | Socket 1151 | 2x DDR4 | SATA-600 | PCI-e 2.0 x1 | PCI-e 3.0 x16 | USB 2.0 | USB 3.1 (Gen1, 5Gb/s) | HDMI | D-Sub
Product: MSI H110M Pro VH Plus
Socket: Socket 1151
Compatible with: 6th and 7th generation processors
Category: motherboards
Brand: MSI
Condition: Used – BIOS updated to the latest version
Warranty: 6 months
EAN: 4719072461065
SKU: H110M PRO-VH PLUS, H110M PRO-VH-PLUS
Package Contents:
– Motherboard (MSI H110M Pro VH Plus)
– IO-Shield (Metal backplate)
– No manual
– No driver CD
– Cables
CPU
Supports 6th Gen Intel® Core™ i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151
Chipset
Intel® H110 Express Chipset
Memory
• 2 x DDR4 memory slots, support up to 32GB
– Supports DDR4 2133 MHz
• Dual channel memory architecture
• Supports Non-ECC, un-buffered memory
• Supports Intel® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs
* DDR4 2133 MHz and higher memory modules will only run at the maximum of DDR4 2133 MHz on XMP mode due to Intel® chipset limitation
Onboard Graphics
• 1 x HDMI™ port, supports a maximum resolution of 4096×2160@24Hz, 2560×1600@60Hz
– Support for HDMI™ 1.4 version.
• 1 x VGA port, supports a maximum resolution of 2048×1536@50Hz, 2048×1280@60Hz, 1920×1200@60Hz
Audio
• Realtek® ALC887 Codec
• 7.1-Channel High Definition Audio
LAN
• 1 x Realtek RTL8111H Gigabit LAN controller
Expansion Slots
• 1 x PCIe 3.0 x16 slot
• 2 x PCIe 2.0 x1 slots
Storage Interface
• Intel® H110 Chipset
• 4 x SATA 6Gb/s ports
USB
Chipset:
– 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the back panel, 2 ports available through the internal USB connector)
– 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
Internal Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power c
Intel | Socket 1151 |
---|---|
Brand | MSI |
Form Factor | Micro-ATX |
Chipset | Intel H110 |
Memory Type | DDR4 SDRAM |
Number of memory slots | 2 |
Maximum memory size | 32 GB |
Connectors | Ethernet (RJ-45), HDMI, USB 2.0, USB 3.0 |
Storage Interfaces | Serial ATA-600 |
Interfaces | PCI-e 2.0 x1, PCI-e 3.0 x16 |
Socket | |
Model | H110M Pro VH Plus |
Length | 22.6 cm |
Width | 17.3 cm |
package content | Motherboard and Backplate (Blende) |
Fast delivery
Product: MSI H110M Pro VH Plus
Socket: Socket 1151
Compatible with: 6th and 7th generation processors
Category: motherboards
Brand: MSI
Condition: Used – BIOS updated to the latest version
Warranty: 6 months
EAN: 4719072461065
SKU: H110M PRO-VH PLUS, H110M PRO-VH-PLUS
