Product information

MSI Z87M Gaming : motherboard |ATX | Intel Socket 1150 | Z87 Chipset | 4x DDR3 (max. 32GB) | PCI-e 2.0 x1 | PCI-e 3.0 x16  | SATA 600 | USB 2.0 | USB 3.0 | ESata | LAN | 2x HDMI | display port

Product: MSI Z87M Gaming
Socket: Socket 1150
Brand: MSI
Condition: Used
EAN: 0719072318659, 0824142017333, 4719072318659
SKU: 7866-001R, Z87M Gaming
Warranty: 6 months

package content:
– Motherboard (MSI Z87M Gaming)
– Backplate (blende)
– No manual
– No driver CD
– No cables

CPU
4th Generation Intel^® Core™ i7 / Core™ i5 / Core™ i3 / Pentium^® / Celeron^® processors for LGA 1150 socket

Chipset
Intel^® Z87 Express Chipset

Memory

• Support four DDR3 1066/1333/1600/1866*/2000*/2133*/2200*/2400*/2600*/2666*/2800*/3000*(*OC) MHz DRAM , 32GB Max
– Dual channel memory architecture
– Supports Intel® Extreme Memory Profile (XMP)
– Supports non-ECC, un-buffered memory

Audio
• Realtek® ALC1150 Codec
– 7.1 Channel High Definition Audio
– Supports S/PDIF output

LAN
• 1x Killer E2205 Gigabit LAN controller

Multi-GPU
• Supports 2-Way AMD CrossFire™ Technology*
* Supports Windows 7 and Windows 8/8.1.

Expansion Slots
• 2 x PCIe 3.0 x16 slots
• 2 x PCIe 2.0 x1 slots

Storage Interface

• SATAIII controller integrated in Intel® Z87 chipset
– Up to 6Gb/s transfer speed.
– Supports six SATA ports (SATA1~6) by Z87
– Supports Intel® Smart Response Technology, Intel® Rapid Start Technology and Intel® Smart Connect Technology*
** Supports Intel Core processors on Windows 7 and Windows 8.

• 2 x SATAIII controller integrated in ASMedia® ASM 1061 chipset
– Up to 6Gb/s transfer speed.
– Supports two e-SATA ports (back panel) by ASM 1061

• RAID
– SATA1~6 ports support Intel Rapid Storage Technology enterprise (RAID 0/1/5/10) by Intel Z87

USB
• Intel Z87 Express Chipset
– 6 x USB 3.0 ports (4 ports on the back panel, 2 ports available through the internal USB connectors)
– 6 x USB 2.0 ports (2 ports on the back panel, 4 ports available through the internal USB connectors)

• RENESAS UPD720202 chipset
– 2 x USB 3.0 ports on the back panel

Internal I/O Connectors

Back Panel Connectors
– 1 x PS/2 keyboard/mouse combo port
– 2 x USB 2.0 ports
– 1 x Clear CMOS button
– 1 x LAN (RJ45) port
– 6 x USB 3.0 ports
– 1 x Optical S/PDIF OUT connector
– 2 x eSATA ports
– 6 x OFC audio jacks
– 2 x HDMI port, supporting a maximum resolution of 4096×2160@24Hz, 24bpp/ 2560×1600@60Hz, 24bpp/ 1920×1080@60Hz, 36bpp
– 1 x DisplayPort with max. resolution up to 4096×2304@24Hz, 2560×1600@60Hz, 3840×2160@60Hz,1920×1200@60Hz

Operating System
Support for Windows 10 64-bit

Form Factor
ATX Form Factor
9.6 in. x 9.6 in. (24.4cm x 24.4cm)
