Product informatie

Moederbord – Socket 1156 | ATX | Intel® Q57 PCH | DDR3 up to 16GB | 2x Gigabit Ethernet | PCI-e 2.0 x16 | PCI-e 2.0 x4 | PCI-e 2.0 x1 | PCI  | 2 x RS232 (DB-9) | USB 2.0 | DVI-I | VGA

Product: DFI PT630 Socket 1156;
Merk: DFI
Staat: Gebruikt
Garantie:
6 Maanden

Drivers voor de DFI PT630

Uitgebreide product specificaties:


CPU
– Supports Socket 1156


Chipset
– Intel® Q57 PCH


Memory
– Dual Channel DDR3 memory technology
– 4 x DDR3 DIMM slots
– Supports DDR3 1333/1066 non-ECC, un-buffered memory
– Max. capacity of system memory: 16GB*


LAN
– Realtek RTL8111DL PCIe (10/100/1000Mbps)
– Intel® W82578DM PCIe with iAMT6.0 (10/100/1000Mbps)


Slots
– 1x PCIe x16 slot (Gen 2)
– 1x PCIe x4 slot (Gen 1)
– 2x PCIe x1 (Gen 1)
– 3x PCI


SATA
– 6x SATA 2.0 (up to 3Gb/s)
– RAID 0/1/5/10


Connector
– ATX 24-Pin power connector
– 4-pin ATX 12V power connector
– 2x RS232/485
– 8x USB 2.0
– 1x Line-out
– 1x Mic-in
– 6x SATA 2.0 (up to 3Gb/s)
– 1x 8-bit DIO


Rear Panel I/O
I/O Panel
– 2x GB Lan
– 2x RS232 (DB-9)
– 4x USB 2.0
– 2x PS/2
– 1x DVI-I
– 1x VGA
– 1x Line-in
– 1x Line-out
– 1x Mic-in


Accessories
– I/O Shield


Form Factor
– ATX


OS

– Microsoft® Windows® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit / Vista™ 32-bit / Vista™ 64-bit / XP 32-bit / XP 64-bit
*Windows® 8.1 is supported with Intel® Ivy Bridge CPU for onboard VGA.

Specificaties

Gewicht 1 kg
Intel

Socket 1156

Merk

DFI

Formaat

ATX

Chipset

Intel Q57 PCH

Geheugentype

DDR3

Aantal geheugenslots

4

Maximale geheugengrootte

16 GB

Aansluitingen

2x RJ-45 LAN, DVI-I, Serial Port: COM1, USB 2.0, VGA

Opslag interfaces

Serial ATA-300

Interfaces

PCI, PCI-e 2.0 x1, PCI-e 2.0 x16, PCI-e 2.0 x4

Socket

Model

PT630

Pakketinhoud

Moederbord en I/O-Shield

Lengte

30.5 cm

Breedte

24.4 cm

PT630 Socket 1156 moederbord

Snelle levering

Product: DFI PT630
Merk: DFI
Socket: 1156
Staat: Gebruikt
Garantie:
6 Maanden


Artikelnummer: PT630 Categorieën: , , Tags: , ,

Voordelen en nadelen
Volgens onze computer expert

  • 4 DDR3 Geheugensloten
